SZLH 350 Series Pellet Mill
SZLH 320 Series Pellet Mill
SZLH 420Series Pellet Mill
SZLH 508 Series Pellet Mill
Product description:
1. Adopt gear transmission to ensure the maximum transfer of energy.
2. Large stainless steel modulator, greatly improving the ripening time and effect.
3. The main drive bearings are Japanese NSK bearings and Swedish SKF bearings.
4. The ring die is connected with the transmission wheel by a quick-release hoop, which makes the ring die easy to disassemble.
5. widely used, it can produce chicken, cattle, sheep, pigs, fish, shrimp and other feed. It is widely used in medium and large farms, large feed processing plants and granulation of compound fertilizers.
6. Pelletizer door and feeding barrel are made of stainless steel with long service life.
7. It can be equipped with single-layer or multi-layer modulators to meet the production requirements of high-grade feed and aquatic products.
Main technical parameters and performance parameters
|
Model |
Total Power(kw) |
Outputs(t/h) |
Floor Area(m) (L×W×H) |
|
SZLH320 |
37+2.2+0.55 |
2-5 |
1.95×1.2×1.86 |
|
SZLH350 |
55+2.2+0.75 |
3-8 |
2.1×1.2×1.95 |
|
SZLH420D |
110+3+1.5 |
3-12 |
3.3×1.47×2.54 |
|
SZLH508 |
132+5.5+1.5 |
4-20 |
3.45×1.47×2.79 |
